Controlled Automation ABL-74T

The ABL-74T angle processing line is the smallest footprint machine on the market capable of processing 6x6x1/2 material with ZERO drop in stock, punching both legs, and cutting with a single-cut shear. We cut out less of your material and process faster than any other small angle line.


  • Punch capacity: 74 ton
  • Shearing capacity: 215 ton
  • Wheel material feed
  • ​Wheel measuring
  • Material positioning speed: 0 to 180 ft/min
  • Positioning accuracy: +/- 1/32”
  • Air conditioned
  • Windows controller
  • Easily networked

Controlled Automation ABL-74T

Technical Data
Minimum Angle 1-1/2 x 1-1/2 x 3/16 in
Maximum Angle 6 x 6 x 1/2 in
Minimum Flat Bar 1/4 x 1-1/2 in
Maximum Flat Bar 1/2 x 6 in
Minimum Material Length 6 ft
Maximum Material Length 40 ft
Maximum Hole Size
1-1/4 in
Machine Weight lb
Machine Dimensions (L x W x H) in
